Overview
The FEREX is a vertical gradient fluxgate magnetometer that measures the deformation of the earth's magnetic field evoked by ferromagnetic objects. Magnetometers are suitable for
the detection of ferromagnetic metals like iron, steel or nickel. Normally the detection Depth of magnetometers is larger compared to active EMI detectors but it varies and depends on
the object's mass and its magnetic properties.
The FEREX 4.034 can be used either in direct meter mode or in data recording mode. Four channels for data recording allow the FEREX 4.034 to be expanded into a multi probe holder system for large area survey. The device offers the possibility to connect alternative sensors and GPS systems via a serial interface. These allow precise navigation and geo-referencing of the recorded data..
Detection of ferrous material/UXO e.g. bombs, shells, projectiles, sub-ammunitions
Detection of underground infrastructure, e.g. tunnels
Magnetometer with tension band technology - provides
sensor alignment for Lifetime
In-built filters for detection in close vicinity to power lines
Special mode for search along fences, pipelines and
railway tracks
Special mode for filtering small objects
Precise handling, light weight, compact design
High detection sensitivity, improved signal to noise ratio
3.5” color sunlight readable display
Data logging of up to 4 FOERSTER fluxgate sensor
channels (differential and absolute values)
Option to link alternative sensors
(e.g. GEOMETRICS® 824A) via serial interface
Serial interface to link various DGPS systems or
odometer
Implemented tool to edit customized GPS-drivers
Comfortable navigation screen and various navigation modes
Integrated stake-out function using imported DATA2LINE object and position lists
Managing large survey areas consisting of multiple survey grids
Definition of various survey grid layouts by defining or importing polygon positioning data
Software DATA2LINE for project definition, post processing and evaluation of recorded
data
Specifications
Transmission frequency | 0.00 kHz |
Audio output | yes |
Visual display | yes |
Depth indication | 6m to 7m |
Sensitive adjustment | 1 |
Ground balance | 1 |
Connectivity | yes |
Battery | 4x 1.5V batteries (LR20) or 4x 1.2V NiMH |
Low battery alert | 1 |
Rechargeable | 1 |
Operating time | 0.00 hours |
Operating time information | 8h for1-channel solution constant usage |
Length | 1250.00 mm |
Weight | 4.10 kg |
Search head size | 550.00 mm |
Shape | 550mm sensor distance probe |
Transport case provided | 1 |
Transport case information | rugged case |
Transport case weight | 8.50 kg |
Factory support | 24/7 through worldwide network |
Warranty | 2 years |
Water resistant | 1 |
Temperature limitations | Control unit: IP65 , probe IP68 |
Base price | 0.00 € |
Reduction for higher quantity | please contact dm.sales@foerstergroup.de |
Possible to rent | 1 |
Price for training | please contact dm.sales@foerstergroup.de |
Additional equipment | Multi probe holder up to 8 fluxgate probes Wheel set GEOMETRICS® 824 A sensor Probe holder for GEOMETRICS® 824A sensor GPS antenna mount Borehole detection kit Waterproof probe cables up to 100 m Headphone |
